Detailed dimensions of the Blitz S1 e-bike, including wheelbase, seat height, handlebar reach, and tube lengths, highlighting its design and ergonomic build.


Rider Height 5'3" to 6'7"
Weight Capacity 400 lbs
a - Handlebar Reach 590 mm
b -Top Tube Length 468 mm
c - Head Tube Length 180 mm
d - Seat Height 870 mm
e - Wheelbase 1113 mm
f - Stand-Over Height 830 mm
g - Chainstay Length 582 mm
h - Fork Length 650 mm
i - Head Tube Angle 66°
j - Stack 496 mm
k - Total Length 1693 mm
l - Handlebar Height 1055mm
